Equipment Specifications
| Model |
Electrode Module (Set) |
Treatment Flow Rate (m³/h) |
Operating Power (kW) |
Equipment Dimensions |
Floor Area (m²) |
| Length (m) |
Width (m) |
Height (m) |
| DHX-CQ/1 |
1 |
1 |
2.47 |
1.5 |
1.8 |
1.7 |
3 |
| DHX-CQ/2 |
2 |
2 |
4.57 |
1.5 |
1.8 |
1.7 |
3 |
| DHX-CQ/4 |
4 |
4 |
9.5 |
2 |
2.5 |
2 |
4 |
| DHX-CQ/8 |
8 |
8 |
19 |
3 |
4 |
2.5 |
9 |
| DHX-CQ/12 |
12 |
12 |
27 |
3.5 |
4 |
2.5 |
12 |
| DHX-CQ/16 |
16 |
16 |
36 |
4 |
4 |
2.5 |
22 |
| DHX-CQ/20 |
20 |
20 |
45 |
4.5 |
4 |
2.5 |
24 |
| DHX-CQ/24 |
24 |
24 |
55 |
5 |
4 |
2.5 |
30 |
| DHX-CQ/28 |
28 |
28 |
63 |
5.5 |
4 |
2.5 |
45 |
| DHX-CQ/32 |
32 |
32 |
72 |
6 |
4 |
2.5 |
30 |
| DHX-CQ/64 |
64 |
64 |
144 |
14 |
5 |
2.5 |
80 |
| DHX-CQ/128 |
128 |
128 |
288 |
22 |
5 |
2.5 |
130 |
Note: The treatment flow rate is not the treatment target. Different types of wastewater and different treatment objectives will result in varying equipment operation durations.
Applicable Scope
Suitable for treating various high-difficulty, refractory organic wastewater streams, including pharmaceutical, chemical, pesticide, laboratory, coal chemical, petrochemical, aquaculture, slaughterhouse, semiconductor, dyeing, painting/coating, landfill leachate, food processing, machining, and domestic wastewater.
Specific contaminant categories addressed: Aromatic compounds (BTEX, phenols, PAHs, aromatic amines, other aromatics); Halogenated organic compounds (halogenated aliphatic hydrocarbons, halogenated aromatic hydrocarbons, persistent halogenated organic compounds); Oxygen-containing organic compounds (alcohols/phenols/ethers, aldehydes/ketones/quinones, carboxylic acids/esters, lactones); Nitrogen-containing organic compounds (amines, nitro/nitroso compounds, amides, nitrogen-containing heterocycles, amino acids); Synthetic polymers/macromolecules (water-soluble polymers, polymeric surfactants, synthetic dyes/pigments, plastic monomers and oligomers); Natural degradation products (humic substances, lignin degradation products, carbohydrate degradation products, protein/fat degradation products, natural toxins/secondary metabolites); PFAS; and other contaminants across different wastewater types.
Equipment Inlet Water Conditions
Influent and Reaction Temperature 1-80℃
pH Range pH: 2-12, and C(H⁺) < 2 mol/L
Fluorine ＜10mg/L(Including organic fluorine and inorganic fluorine)
Bromine ＜500mg/L
SS (Suspended Solids) ＜200mg/L
Salinity Content ＜Saturation
Equipment process
For wastewater with special characteristics or unique treatment objectives, our company's engineers provide technical support and solutions.
Working Characteristics of CQDHX SERIES EO Electrode Modules
No chemical agents need to be added, and no residues or solid wastes are generated! The modular electrodes are free from scaling and clogging!
Alias: BDD oxidation equipment
Parameter: 1-30T/h
Process: BDD
Material: Corrosion-resistant
Application: Removal of organics and ammonia nitrogen from wastewater
Customized service: Customizable on demand
